Sarthak TMT

Sarthak TMT

Choose Sarthak, India's No. 1 TMT bars for structural integrity. Sarthak TMT Bars are produced from the finest grade DRCLO and other raw materials to provide better mechanical & chemical properties. Thus, they come with superior strength and ductility to enhance the life of every construction and help build a stronger nation. Sarthak TMT Bars have been a preferred choice for many top-notch consultants, architects, and engineers for infrastructural projects.

	Parameters	As Per IS 1786:2008 Fe500 D	Sarthak Fe500D	As Per IS 1786:2008 Fe550 D	Sarthak Fe550D	As Per IS 1786:2008 Fe600	Sarthak Fe600
Chemical Composition	%C (Max)	0.25	0.2	0.25	0.25	0.3	0.28
	%P (Max)	0.04	0.038	0.04	0.038	0.04	0.038
	%S (Max)	0.04	0.37	0.04	0.37	0.04	0.37
	S+P (Max)	0.075	0.075	0.075	0.075	0.075	0.075
	CE (Max)	AS Per IS 1786

	Parameters	As Per IS 1786:2008 Fe500 D	Sarthak Fe500D	As Per IS 1786:2008 Fe550 D	Sarthak Fe550D	As Per IS 1786:2008 Fe600	Sarthak Fe600
Mehcanical Properties	YS N/Mm2	500	530	550	560	600	620
	TS N/Mm2	565	640	600	660	660	680
	UTS/YS Ratio	1.1	1.2	1.08	1.15	1.06	1.08
	% Elongation (Min)	16	18.5	14.5	17	10	12
	%T EL (Min)	5	5	5	5	-	-

	Parameters	As Per IS 1786:2008 Fe500 D	Sarthak Fe500D	As Per IS 1786:2008 Fe550 D	Sarthak Fe550D	As Per IS 1786:2008 Fe600	Sarthak Fe600
Bend Properties	Mandrel Dia Upto And including 20 Mm (Max)	4d	4d	4d	4d	5d	5d
	Mandrel Dia Over 20 Mm (Max)	5d	5d	5d	5d	6d	6d

	Parameters	As Per IS 1786:2008 Fe500 D	Sarthak Fe500D	As Per IS 1786:2008 Fe550 D	Sarthak Fe550D	As Per IS 1786:2008 Fe600	Sarthak Fe600
Re-Bend Properties	Mandrel Dia Upto And including 10 Mm (Max)	4d	4d	6d	6d	7d	7d
	Mandrel Dia Over 10 Mm (Max)	6d	6d	7d	7d	9d	9d

*Values As per is 1786:2008, Amnd No. 4
Actual value can be considered as per MTC
