Sarthak CRS TMT
In challenging construction environments with high salinity, industrial settings, and marine structures, choose Sarthak CRS. Sarthak TMT Fe 500D CRS, Fe 550 CRS, and Fe 600 CRS grades offer robust strength and corrosion resistance—ideal for your construction needs. Build with confidence, build with Sarthak CRS.
![](other-images/sarthak-crs-tmt.jpg)
Specifications of Sarthak CRS TMT Bars
Parameters | As Per IS 1786:2008 Fe500 D |
Sarthak Fe500D CRS | As Per IS 1786:2008 Fe550 D |
Sarthak Fe550D CRS | As Per IS 1786:2008 Fe600 |
Sarthak Fe600 CRS | |
---|---|---|---|---|---|---|---|
![]() Chemical Composition |
%C (Max) | 0.15 | 0.14 | 0.15 | 0.15 | 0.15 | 0.15 |
%S (Max) | 0.04 | 0.03 | 0.04 | 0.03 | 0.04 | 0.04 | |
%P (Max) | 0.12 | 0.1 | 0.12 | 0.08 | 0.12 | 0.08 | |
CE (Max) | AS Per IS 1786 |
Parameters | As Per IS 1786:2008 Fe500 D |
Sarthak Fe500D CRS | As Per IS 1786:2008 Fe550 D |
Sarthak Fe550D CRS | As Per IS 1786:2008 Fe600 |
Sarthak Fe600 CRS | |
---|---|---|---|---|---|---|---|
![]() Mehcanical Properties |
YS N/Mm2 | 500 | 540 | 550 | 570 | 600 | 620 |
TS N/Mm2 | 565 | 640 | 585 | 630 | 660 | 670 | |
UTS/YS Ratio | 1.1 | 1.15 | 1.08 | 1.15 | 1.06 | 1.08 | |
% Elongation (Min) | 16 | 17 | 14.5 | 16 | 10 | 12 | |
%T EL (Min) | 5 | 5 | - | - | - | - |
Parameters | As Per IS 1786:2008 Fe500 D |
Sarthak Fe500D CRS | As Per IS 1786:2008 Fe550 D |
Sarthak Fe550D CRS | As Per IS 1786:2008 Fe600 |
Sarthak Fe600 CRS | |
---|---|---|---|---|---|---|---|
![]() Bend Properties |
Mandrel Dia Upto And including 20 Mm (Max) | 3d | 3d | 4d | 4d | 5d | 5d |
Mandrel Dia Over 20 Mm (Max) | 4d | 4d | 5d | 5d | 6d | 6d |
Parameters | As Per IS 1786:2008 Fe500 D |
Sarthak Fe500D CRS | As Per IS 1786:2008 Fe550 D |
Sarthak Fe550D CRS | As Per IS 1786:2008 Fe600 |
Sarthak Fe600 CRS | |
---|---|---|---|---|---|---|---|
![]() Re-Bend Properties |
Mandrel Dia Upto And including 10 Mm (Max) | 4d | 4d | 5d | 5d | 6d | 6d |
Mandrel Dia Over 10 Mm (Max) | 6d | 6d | 6d | 6d | 8d | 8d |
*Values As per is 1786:2008, Amnd No. 4
Actual value can be considered as per MTC
Versatile Applications: Thriving in Diverse Environments
![Sarthak TMT](other-images/sarthak-crs-tmt-1.jpg)
- Coastal Regions
- Industrial Zones
- Marine Structures
- High-Acid Atmospheres
- Agricultural Installations
- Urban Construction
- and more...
